KNX-20E-640

640 mA KNX Power Supply

Features

EIB / KNX power supply with integrated choke

Compact size with 3SU(52.5) width

Safety extra low voltage(SELV)

180~264VAC input

No load power consumption

Protections: Short circuit / Overload(short-circuit-proof) / Over voltage

Cooling by free air convection

Isolation class 1

LED indicator for normal operation, bus reset and bus overload

Installed on DIN rail TS-35/7.5 or 15

100% full load burn-in test

3-year warranty

MODEL		KNX-20E-640
OUTPUT	BUS OUTPUT VOLTAGE WITH CHOKE	Bus,30V (KNX black/red terminal block)
	DC OUTPUT VOLTAGE WITHOUT CHOKE	30V(Additional output for ancillary power)
	RATED CURRENT	640mA
	RATED POWER	19.2W
	RIPPLE & NOISE (max.)	100mVp-p
	SHORT CIRCUIT CURRENT	1.4A
	SETUP, RISE TIME	1000ms, 50ms/230VAC at full load
	AC MAINS FAILURE BACK-UP TIME(Typ.)	200ms/230VAC at full load
INPUT	VOLTAGE RANGE	180 ~ 264VAC 254 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	86%
	AC CURRENT (Typ.)	0.22A/230VAC
	INRUSH CURRENT (Typ.)	COLD START 40A/230VAC
	LEAKAGE CURRENT	< 1mA / 240VAC
